(With critical parts, we encourage customers to use Genuine Factory parts from the dealer's parts department.).įield 3: Fuel Rail Pressure (High), Specification: 25.0.110.0 bar

Faulty in-tank fuel pump and/or in-tank fuel pump controller.

Fuel filter issues including restricted/clogged or incorrect part number (wrong pressure relief value).

A value fluctuating ≈ 35% to 95% may indicate an intake fuel pump failing.

A value above ≈ 60% to 70% usually indicates there is a failure or restriction.

A value ≈ 55% to 60% could be considered as an indication of a low fuel pressure concern.

Those engines do not use a G410 (Low) Fuel Pressure Sensor so Measuring Blocks group 103 is not applicable.įield 2: Fuel Rail,Pressure (actual): (A value ≈ 35 to 55% is considered normal at idle)

Timing chain driven engines such as the CCTA, CBFA and CCTA were phased in during model year 2008.

Stay on the pedals as long as the procedure lasts.įield 1: Fuel Pressure (Low), Specification: 2800.7200 mbarįield 2: Fuel Pump Adaptation, Specification: -1000.+1000 %

It may damage the new part.įirmly press Brake Pedal and Throttle Pedal (Full Throttle) at once to activate the basic setting.įield 1 shows the steps counter, which counts down to 0 - then setting readiness is done. Never run Basic Settings with the IMRC motor linkage disconnected from the intake manifold.Those engines use an entirely different IMRC system which uses engine vacuum in conjunction with a solenoid so Basic Settings 142 must be completed at idle. Switch Ignition OFF for at least 60 seconds.Those engines do not use a G410 (Low) Fuel Pressure Sensor so Basic Settings 103 is not applicable.

Observe Field 4, once the adaptation is successfully done it should show "ADP. Press the pedal to the floor and hold it there for at least 2 seconds. Audi A3 (8P) / Seat Altea/Toledo (5P) / Seat Leon (1P) / Skoda Octavia (1Z) / VW Golf (1K)Īutomatic Transmission "multitronic" (01J)įront-Wheel-Drive (FWD) / Climate Control not equippedįront-Wheel-Drive (FWD) / Climate Control equippedĪll-Wheel-Drive (AWD) / Climate Control not equippedĪll-Wheel-Drive (AWD) / Climate Control equipped
